Type 8176
Universal Board 2 Type 8176
Type 8176 is the 532 mm version of the modular control-engineering system of series 9500. It provides a clear, modular experiment setup with central supply and can be expanded with additional functional modules.
- Modular training system for fundamental control engineering
- 532 mm version of the Universal Board
- Only the modules required for the experiment are inserted
- Central operating-voltage supply for short setup times
- Expandable with MOTOR BOARD, SERVO BOARD and temperature/light control section
- Detailed experiment descriptions
Modular concept
Type 8176 is designed as a Universal Board for control engineering. The experiment setup stays clear because only the modules required for the task are inserted.
Expansion
The system can be expanded with a MOTOR BOARD, SERVO BOARD and the temperature/light control section. This makes the board suitable for both introductory and advanced control-engineering experiments.
- System
- Series 9500, control engineering
- Board width
- 532 mm
- Supply
- central operating-voltage supply
- Expandable with
- MOTOR BOARD, SERVO BOARD, temperature/light control section
Taken from the tables of contents of the hps experiment manuals (titles, numbers and pages). All manuals are German; titles are shown in the original language. All manuals and experiments
V 0022 Versuche zum Frequenzumrichter Digital Manual · 120 pages 2 experiments
Mentioned in 2 experiments View table of contents
- 8.1 Drehzahlregelung unabhängig von der Belastung p. 70
- 8.2 Drehzahlregelung mit Sollwertsprung p. 73
No experiment matches the filter.
V 0120 Einführung in die Regelungstechnik Manual · 165 pages 0 experiments
Additional device in this manual View table of contents
No experiment matches the filter.
