Type 3920
DIGI IC BOARD Type 3920
The DIGI IC BOARD Type 3920 is a practical training unit for building circuits with standard IC components. It combines IC sockets, a signal source, displays and a power supply in a compact setup for digital and microcomputer technology.
- Signal source for connecting an A/D converter
- 2-digit hexadecimal/dual code switch with buttons
- 8 IC sockets with 24 pins for DIL ICs
- 1 28-pin IC socket and 1 40-pin IC socket
- 10-pin round socket for ICs and transistors
- 9 branching points for standard components
Practical IC Circuit Platform
The DIGI IC BOARD is intended for building circuits with standard IC components in digital and microcomputer technology. The experiments can be assembled without soldering and with short preparation times.
The front panel provides numerous built-in functional groups, including a signal source, code switch, 7-segment display, LED display, adapter fields and socket rows for supplying the inserted ICs.
Operation and Expansion
The board can be used on a table or mounted in an hps table or frame stand for demonstrations. In the box version it becomes a mobile training unit.
Extensions are possible with accessory set Type 3920.1, IC set Type 3920.5 and box Type 3920.20.
- Fast experiment setup without soldering
- Input and output units plus power supply built into the device
- Mains supply
- 220 V AC ... 240 V AC / 115 V AC (110 V AC), approx. 30 VA, 50 ... 60 Hz
- Signal source
- 0 ... 5 V DC / 10 mA, short-circuit proof
- Internal DC supply
- +5 V / 3 A, short-circuit proof
- External DC supply
- +5 V / 0.5 A, short-circuit proof
- Clock generator
- 100 kHz
- Frequency divider
- 10 kHz, 1 kHz, 100 Hz, 10 Hz, 1 Hz, 0.1 Hz
- High sockets
- 26 sockets for high level or +5 V
- Low sockets
- 25 sockets for low level or GND
- 7-segment display
- two-digit, dual/7-segment decoder
- LED display
- 12-fold, three colour groups red, yellow, green
- Adapter
- 2 mm to 25-pin SUB-D
- Adapter fields
- 4 fields from 4 mm to 2 mm
- Socket rows
- 14 rows with 2 mm sockets
- Board version
- 532 x 297 x 110 mm
- Weight board version
- approx. 3.8 kg
- Box version
- 580 x 450 x 155 mm
- Weight box version
- approx. 7 kg
- Recommended accessories
- Accessory set 3920.1, IC set 3920.5, box 3920.20
- Build circuits with standard IC components
- Use the signal source as an A/D input
- Set hexadecimal and dual coding
- Evaluate 7-segment and LED displays
- Use the clock and frequency divider
- Combine experiments with external equipment
