Type 2200
Installation Technology Demo Boards Series 2200
For carrying out the experiments, the demonstration boards are inserted into hps table or demonstration frames. The accompanying teaching material is the experiment manual V 0081, which contains numerous circuits and installation diagrams.
- Didactically mature training system for installation technology
- Designed for vocational and continuing education in installation technology
- Demonstration boards with graphically displayed current paths on the front
- Detailed experiment descriptions with circuit and installation diagrams
- Wiring with safety leads and 4 mm sockets
- Rear side protected against contact
System Overview
The training system consists of demonstration boards for installation technology and is inserted into hps table or demonstration frames.
It is suitable for vocational training, student workstations and classroom demonstrations.
Series Components
- Type 2290 - Single-phase power supply, 220 ... 240 V AC; 16 A; with residual current device; circuit breaker 16 A; contactor control with key switch and emergency stop.
- Type 2297 - Current relay; adjustment range 0.1 ... 1 A; 1 change-over contact; 250 V AC; 3 A; auxiliary supply 220 ... 240 V AC; 50 ... 60 Hz.
- Type 2200 - Single-pole switch, 250 V AC; 10 A.
- Type 2201 - Double-pole switch, 250 V AC; 10 A.
- Type 2202 - Series switch, 250 V AC; 10 A.
- Type 2203 - Dimmer 400 W; 220 ... 240 V AC; for stepless control of resistive loads.
- Type 2204 - Two-way switch, 250 V AC; 10 A.
- Type 2206 - Socket outlet, 250 V AC; 16 A.
- Type 2212 - Remote switch; operating voltage 220 ... 240 V AC; 2 normally open contacts.
- Type 2213 - Staircase light time switch; 1 ... 6 minutes.
- Type 2214 - E 27 lamp holder with incandescent lamp; 220 ... 240 V AC; 60 W.
Technical Data
Dimensions of the demonstration boards: 95 x 297 mm and 266 x 297 mm.
The front panels are made of 5 mm laminated fibreboard in blue.
- Can be inserted into table or demonstration frames
- Recommended experiment manual V 0081
- System
- Demonstration boards for installation technology; inserted into table or demonstration frames.
- Front panel material
- 5 mm laminated fibreboard, blue.
- Dimensions
- 95 x 297 mm and 266 x 297 mm; depths vary by type.
- Experiment manual
- V 0081
